AMPIRE AM-800480R3HMQW-A1H LCD

Specification

Model P/N:AM-800480R3HMQW-A1H
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 134PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/50/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×86.64(H) mm
Bezel Opening:156.2(W)×90.3(H) mm
Outline Dim:165(H)×104.44(V) ×6.71(D) mm
Treatment:-
Luminance:500 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:5/20 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:65K/262K
Light Source:WLED , 50K hours , With LED Driver
Weight:-
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
