AMPIRE AM-800480GTMQW-T01H-A LCD

Specification

Model P/N:AM-800480GTMQW-T01H-A
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Brightness:240 cd/m² (Typ.)
Contrast Ratio:250:1 (Typ.) (TM)
Viewing Angle:70/70/60/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:154.9(W)×93.9(H) mm
Response Time:20 (Typ.)(Tr+Td)
Outline Size:165(W)×104(H) ×5.86(D) mm
Surface:-
Best View on:-
Display Colors:262K 50% NTSC
Lamp Type:3S7P WLED , 30K hours , With LED Driver
Frequency:60Hz
Touch Screen:4-wire Resistive Touch
Panel Weight:-
Application:Industrial
Signal Interface:Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Input Voltage:3.3V (Typ.)
