AMPIRE AM-800480GTMQW-05H LCD

Specification

Model P/N:AM-800480GTMQW-05H
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Contrast Ratio:250 : 1 (Typ.) (TM)
Viewing Angle:70/70/60/60 (Typ.)(CR≥10)
Color Depth:262K 50% NTSC
Backlight:WLED , With LED Driver
Signal Type:Parallel RGB (1 ch, 6-bit) , Connector 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:154.9(W)×93.9(H) mm
Treatment:Antiglare
Luminance:280 cd/m² (Typ.)
Response:20 (Typ.)(Tr+Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C
Outline (mm):165×104×4.3 (H×V×D)
