AMPIRE AM-800480D4TMQW-TA3H LCD

Specification

Model P/N:AM-800480D4TMQW-TA3H
Brand:AMPIRE
Diagonal Size:8.0"
Resolution:800(RGB)×480, WVGA 116PPI
Contrast Ratio:500 : 1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Color Depth:262K
Backlight:WLED , 20K hours , With LED Driver
Signal Type:LVDS (1 ch, 6-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:176.64(W)×99.36(H) mm
Bezel Opening:-
Treatment:-
Luminance:380 cd/m² (Typ.)
Response:10/15 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Industrial
Refresh Rate:-
Touchscreen:PCAP, USB
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 80 °C
Outline (mm):212.8×136.9×13.23 (H×V×D)
