AMPIRE AM-7201280ETZQW-00H LCD

Specification

Model P/N:AM-7201280ETZQW-00H
Brand:AMPIRE
Diagonal Size:5.0"
Resolution:720(RGB)×1280, WXGA 294PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:62.1(W)×110.4(H) mm
Bezel Opening:-
Outline Dim:65.4(H)×118.9(V) ×1.65(D) mm
Treatment:-
Luminance:430 cd/m² (Typ.)
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:IPS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:WLED [6S2P] , 20K hours , W/O Driver
Weight:-
Designed For:Handheld & PDA
Frame Rate:60Hz
Touch Panel:Without
Interface Type:MIPI (4 data lanes) , 34 pins Connector
Power Supply:1.8/2.8V (Typ.)(VDDIO/VDD)
