AMPIRE AM-480272MGTZQW-00H LCD

Specification

Model P/N:AM-480272MGTZQW-00H
Brand:AMPIRE
Diagonal Size:4.3"
Resolution:480(RGB)×272, WQVGA 128PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 51% NTSC
Backlight:6S2P WLED , 25K hours , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) , 40 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:95.04(W)×53.856(H) mm
Bezel Opening:97.6(W)×56.0(H) mm
Treatment:-
Luminance:500 cd/m² (Typ.)
Outline(mm):105.6 × 67.2 × 3.1 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Mass:-
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
