AMPIRE AM-320480B5TNQW-00H LCD

Specification

Model P/N:AM-320480B5TNQW-00H
Brand:AMPIRE
Diagonal Size:3.5"
Resolution:320(RGB)×480, HVGA 166PPI
Contrast Ratio:500 : 1 (Typ.) (TM)
Viewing Angle:70/70/70/60 (Typ.)(CR≥10)
Color Depth:262K 60% NTSC
Backlight:WLED , 20K hours , No Driver
Signal Type:CPU/RGB/SPI , 40 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:48.96(W)×73.44(H) mm
Bezel Opening:-
Treatment:-
Luminance:450 cd/m² (Typ.)
Outline(mm):58 × 87 × 3.1 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Handheld & PDA
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:2.8/3.3V (Typ.)(VCI/IOVCC)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
