AMPIRE AM-320240NTMQW-W0H-A(R) LCD

Specification

Model P/N:AM-320240NTMQW-W0H-A(R)
Brand:AMPIRE
Diagonal Size:5.7"
Resolution:320(RGB)×240, QVGA 70PPI
Brightness:500 cd/m² (Typ.)
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:60/60/60/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:115.2(W)×86.4(H) mm
Bezel Opening:118.2(W)×89.4(H) mm
Response Time:15/35 (Typ.)(Tr/Td)
Outline Size:131(W)×102.2(H) ×12.7(D) mm
Surface:-
Best View on:12 o'clock
Display Colors:65K/262K 61% NTSC
Lamp Type:3S7P WLED , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Industrial
Signal Interface:6/8/9/16/18-bit 6800/8080 , 40 pins FPC
Input Voltage:5.0V (Typ.)
