AMPIRE AM-320240LATNQW-00H-G LCD

Specification

Model P/N:AM-320240LATNQW-00H-G
Brand:AMPIRE
Diagonal Size:3.5"
Resolution:320(RGB)×240, QVGA 115PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Color Depth:262K
Backlight:3S2P WLED , 20K hours , No Driver
Signal Type:Parallel RGB (1 ch, 6-bit) , FPC 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:70.08(W)×52.56(H) mm
Bezel Opening:73.7(W)×55.3(H) mm
Treatment:Antiglare
Luminance:500 cd/m² (Typ.)
Response:50 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Industrial ，Handheld & PDA ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):77.8×64.5×4.7 (H×V×D)
