AMPIRE AM-240320D5TOQW-T00H(R) LCD

Specification

Model P/N:AM-240320D5TOQW-T00H(R)
Brand:AMPIRE
Diagonal Size:3.2"
Resolution:240(RGB)×320, QVGA 125PPI
Contrast Ratio:200:1 (Typ.) (TM)
Viewing Angle:39/15/63/63 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:48.6(W)×64.8(H) mm
Bezel Opening:-
Outline Dim:55.64(H)×77.3(V) ×6.3(D) mm
Treatment:-
Luminance:160 cd/m² (Typ.)
View Direction:9 o'clock
Response Time:15/35 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 60% NTSC
Light Source:WLED [6S1P] , W/O Driver
Weight:TBD
Designed For:Handheld & PDA
Frame Rate:60Hz
Touch Panel:4-wire Resistive Touch
Interface Type:CPU/RGB/SPI , 45 pins FPC
Power Supply:2.8V (Typ.)
