AMPIRE AM-1024768R3TNQW-T00H LCD

Specification

Model P/N:AM-1024768R3TNQW-T00H
Brand:AMPIRE
Diagonal Size:12.1"
Resolution:1024(RGB)×768, XGA 105PPI
Brightness:300 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:245.76(W)×184.32(H) mm
Bezel Opening:-
Response Time:16 (Typ.)(Tr+Td)
Outline Size:279(W)×209(H) ×11.2(D) mm
Surface:-
Best View on:-
Display Colors:262K/16.7M
Lamp Type:WLED , 30K hours , With LED Driver
Frequency:60Hz
Touch Screen:PCAP, USB
Panel Weight:-
Application:Industrial
Signal Interface:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
