AMPIRE AM-1024600DTZQW-TH0H LCD

Specification

Model P/N:AM-1024600DTZQW-TH0H
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 170PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 58% NTSC
Backlight:WLED , 30K hours , With LED Driver
Signal Type:HDMI , Connector 19 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.214(W)×85.92(H) mm
Bezel Opening:-
Treatment:-
Luminance:425 cd/m² (Typ.)
Response:13/15 (Typ.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Mass:-
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:PCAP, USB
Voltage Supply:12.0V (Typ.)(With Backight)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):184×128×24.75 (H×V×D)
