ACX705AKM SONY LCD panel replacement for Handheld & PDA

Brand：SONY
Model：ACX705AKM
Diagonal Size：2.7 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：240(RGB)×160[HQVGA]
Configuration： RGB Vertical Stripe
Active Area：57.6(H)×38.4(V) mm
Outline Dim.：71.4(H)×52(V) mm
Bezel Area：60.0(H)×40.8(V) mm
Treatment：-
Luminance：5 cd/m2 (Typ.)
Contrast Ratio： 13:1 (Typ.) (RF)
View Direction：-
Response Time：5/10 (Typ.)(Tr/Td)
Viewing Angle：60/60/40/60 (Typ.)(CR≥2)
Operating Mode：TN， Normally White， Reflective
Support Color：512
Light Source：WLED， W/O Driver
Weight： –
Designed For： Handheld & PDA,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 22 pinsParallel RGB (1 ch， 3-bit)， FPC
Power Supply：3.8/3.0V (Typ.)(VCC1/VCC2)
Environment： Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C：：
