Mitsubishi AC150XA03 LCD

Specification

Model P/N:AC150XA03 6
Brand:Mitsubishi
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:700 : 1 (Typ.) (TM)
Viewing Angle:80/80/70/70 (Typ.)(CR≥10)
Color Depth:262K/16.7M 60% NTSC
Backlight:WLED , 100K hours , With LED Driver
Signal Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.4(W)×231.3(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:450 cd/m² (Typ.)
Outline(mm):326.5 × 253.5 × 12.5 (H×V×D)
Response:2/10 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:1.05Kgs (Typ.)
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C
