AA170EB01 Mitsubishi LCD panel replacement for Industrial Application

Panel Brand：Mitsubishi
Panel Size：17.0 inch
Resolution：1280(RGB)×1024 , SXGA
Display Area：337.92(W)×270.336(H) mm
Outline Size：358(W)×296.5(H)×17.4(D) mm
Brightness：550 cd/m2 (Typ.)
Viewing Angle：80/80/80/60 (Typ.)(CR≥10)
Best View on：6 o'clock
Display Colors：262K/16.7M72%(CIE1931)
Frequency： 60Hz
Weight：1.84Kgs (Typ.)
Panel Model：AA170EB01 1 Compatible
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：341.6(W)×274.0(H) mm
Surface：Antiglare, Hard coating (3H)
Contrast Ratio：800:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：6/19 (Typ.)(Tr/Td)
Lamp Type： 4 pcs CCFL , 50K hours , Without Driver
Touch Screen：Without
Application： Industrial Application,
Signal Interface： LVDS (2 ch, 6/8-bit), 30 pins , Connector
Input Voltage： 3.3/5.0V (Typ.)
Environment： Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -20 ~ 80 °C
