Mitsubishi AA150XW14--G1 LCD

Specification

Model P/N:AA150XW14--G1
Brand:Mitsubishi
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:308.1(W)×232.1(H) mm
Outline Dim:326(H)×255(V) ×13.3(D) mm
Treatment:Antiglare, Antireflection
Luminance:1000 cd/m² (Typ.)
View Direction:Symmetry
Response Time:12/12 (Typ.)(Tr/Td)
Operating Mode:SWV, Normally Black, Transmissive
Support Color:262K/16.7M 72% NTSC
Light Source:WLED [5 strings] , 100K hours , W/O Driver
Weight:1350g (Typ.)
Designed For:Industrial ，Outdoor High Brightness
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
