AA121SL12 Mitsubishi LCD panel replacement for Industrial Application

Manufacturer：Mitsubishi
Model Name：AA121SL12
Screen Size：12.1 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：800(RGB)×600 (SVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：246 × 184.5 (H×V)
Outline(mm)： 280 × 210× 12.5 (H×V×D)
Bezel Area(mm)：249.0 × 187.5 (H×V)
Treatment：Antiglare, Hard coating (3H)
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle：65/65/75/45 (Typ.)(CR≥10)
Response：10/30 (Typ.)(Tr/Td) ms
Good View at：6 o'clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K/16.7M
Backlight：2 pcsCCFL, 50K hours, No Driver
Mass： 750g (Typ.)
Used for： Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch, 6/8-bit), Connector , 20 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings：： Storage Temp.: -30 ~ 80 °COperating Temp.: -20 ~ 70 °C
