Mitsubishi AA104VC02 LCD

Specification

Model P/N:AA104VC02 1
Brand:Mitsubishi
Diagonal Size:10.4"
Resolution:640(RGB)×480, VGA 76PPI
Brightness:430 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:65/65/45/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:215.4(W)×161.8(H) mm
Response Time:10/30 (Typ.)(Tr/Td)
Outline Size:243(W)×181.6(H) ×12.7(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K 40% NTSC
Lamp Type:2 pcs CCFL , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:540g (Typ.)
Application:Industrial
Signal Interface:CMOS (1 ch, 6-bit) , 31 pins Connector
Input Voltage:3.3/5.0V (Typ.)(VCC)
