Mitsubishi AA104VB02 LCD

Specification

Model P/N:AA104VB02 1
Brand:Mitsubishi
Diagonal Size:10.4"
Resolution:640(RGB)×480, VGA 76PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:60/60/45/55 (Typ.)(CR≥10)
Color Depth:262K 35% NTSC
Backlight:2 pcs CCFL , 50K hours , No Driver
Signal Type:CMOS (1 ch, 6-bit) , Connector 31 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:215.4(W)×161.8(H) mm
Treatment:-
Luminance:400 cd/m² (Typ.)
Response:15/35 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:530g (Typ.)
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):243×181.6×12.7 (H×V×D)
