Mitsubishi AA104SH02 LCD

Specification

Model P/N:AA104SH02 1
Brand:Mitsubishi
Diagonal Size:10.4"
Resolution:800(RGB)×600, SVGA 96PPI
Brightness:700 cd/m² (Typ.)
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:80/80/80/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:215.4(W)×161.8(H) mm
Response Time:4/12 (Typ.)(Tr/Td)
Outline Size:230(W)×180.2(H) ×11(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K/16.7M 40% NTSC
Lamp Type:2 strings WLED , 100K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:520g (Typ.)
Application:Industrial
Signal Interface:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
