Mitsubishi AA084XB01--T2 LCD

Specification

Model P/N:AA084XB01--T2
Brand:Mitsubishi
Diagonal Size:8.4"
Resolution:1024(RGB)×768, XGA 152PPI
Contrast Ratio:570:1 (Typ.) (TM)
Viewing Angle:80/80/80/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:170.496(W)×127.872(H) mm
Bezel Opening:174.9(W)×132.2(H) mm
Outline Dim:199.5(H)×149(V) ×14.3(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:400 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:4/12 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K/16.7M 40% NTSC
Light Source:WLED [2 strings] , 100K hours , W/O Driver
Weight:500g (Typ.)
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:4-wire Resistive Touch
Interface Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
