AA035AE01 Mitsubishi LCD panel replacement

Manufacturer：Mitsubishi
Screen Size： 3.5 inch
Pixel Number： 960(RGB)×540(qHD)
Active Area(mm)：77.76 × 43.74 (H×V)
Bezel Area(mm)：80.16 × 46.14 (H×V)
Luminance：400 (Typ.)(cd/m2)
Viewing Angle：85/85/85/85 (Typ.)(CR≥10)
Good View at：Symmetry
Color Depth：262K 72% (CIE1931)
Mass： 43.0g (Typ.)
Refresh Rate：60Hz
Model Name：AA035AE01
Screen Type：LCM ,a-Si TFT-LCD
Arrangement：RGB Vertical Stripe
Outline(mm)： 90 × 57(H×V×D)
Treatment：Clear, Hard coating (3H)
Contrast Ratio： 800 : 1 (Typ.) (TM)
Work Mode： IPS, Normally Black, Transmissive
Response：12/12 (Typ.)(Tr/Td) ms
Backlight：3 strings WLED, No Driver
Used for： Industrial Application, Digital Video Camera,
Touchscreen：Without
Signal Type：LVDS (1 ch, 6-bit), FPC, 30 pins
Voltage Supply： 2.5/3.2V (Typ.)(VDD/VCC)
Max. Ratings： Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
