A260J2-001 Innolux LCD panel replacement for Desktop Monitor

Panel Brand：CMO
Panel Size：25.5 inch
Resolution：1920(RGB)×1200 , WUXGA
Display Area：550.08(W)×343.8(H) mm
Outline Size：582(W)×375.6(H) mm
Brightness：600 cd/m2 (Typ.)
Viewing Angle：85/85/80/80 (Typ.)(CR≥10)
Best View on：6 o’clock
Display Colors：16.7M
Frequency：-
Weight：3.35Kgs (Max.)
Panel Model：A260J2-001
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：554.1(W)×347.8(H) mm
Surface：Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio：800:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：1/4 (Typ.)(Tr/Td)
Lamp Type： 16 pcs CCFL , 50K hours , Without Driver
Touch Screen：Without
Application： Desktop Monitor,
Signal Interface： RSDS (2 Channel), 90 pins , Connector
Environment： Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
