A090VW01 V3 AUO LCD panel replacement for Touchscreen

Manufacturer：AUO
Model Name：A090VW01 V3
Screen Size：9.0 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：800×480(RGB) (WVGA)
Arrangement：RGB Horizontal Stripe
Active Area(mm)：199.2 × 110.16 (H×V)
Outline(mm)： 211.7 × 125 (H×V×D)
Bezel Area(mm)：201.2 × 112.16 (H×V)
Treatment：Antiglare, Hard coating (3H)
Luminance：250 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle：70/70/55/70 (Typ.)(CR≥10)
Response：4/12 (Typ.)(Tr/Td) ms
Good View at：-
Work Mode：TN, Normally White, Transmissive
Color Depth：16.7M 48%(CIE1931)
Backlight：3S8PWLED, 10K hours, No Driver
Mass： 220g (Typ.)
Used for： Digital Photo Frame, Portable DVD Player, Industrial Application,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： TTL (1 ch, 8-bit) + SPI, FPC , 68 pins
Voltage Supply：3.3/5.5/-5.5/10/-13V (Typ.)(VCC/VDPA/VDNA/VGH/VGL)
Max. Ratings： Storage Temp.: -20 ~ 70 °COperating Temp.: -10 ~ 60 °C
