A089SW01 V1 AUO LCD panel replacement for Netbook PC

Brand：AUO
Model：A089SW01 V1
Diagonal Size：8.9 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：1024(RGB)×600[WSVGA]
Configuration：RGB Vertical Stripe
Active Area：195.072(H)×113.4(V) mm
Outline Dim.：213.36(H)×129.55(V)×5.45(D) mm
Bezel Area：198.27(H)×116.6(V) mm
Treatment：Glare (Haze 0%)
Luminance：180 cd/m2 (Typ.)
Contrast Ratio：300:1 (Typ.) (TM)
View Direction：-
Response Time：12/18 (Typ.)(Tr/Td)
Viewing Angle：40/40/20/40 (Typ.)(CR≥10)
Operating Mode：TN， Normally White， Transmissive
Support Color：262K
Light Source：WLED[3S8P]， 10K hours， With LED Driver
Form Style： –
Designed For： Netbook PC,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch， 6-bit)， Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
