A070VTN06.4 AUO LCD panel replacement

Brand：AUO
Diagonal Size：7.0 inch
Pixel Format：800(RGB)×480[WVGA]
Active Area：154.08(H)×85.92(V) mm
Luminance：500 cd/m2 (Typ.)
View Direction：6 o'clock
Viewing Angle：70/70/60/60 (Typ.)(CR≥10)
Support Color：16.7M
Weight：TBD
Frame Rate： 60Hz
Model：A070VTN06.4
Type：a-Si TFT-LCD ， LCM
Configuration：RGB Vertical Stripe
Outline Dim.：-
Contrast Ratio：-
Response Time：25 (Typ.)(Tr+Td)
Operating Mode： TN， Normally White， Transmissive
Light Source： WLED ， W/O Driver
Designed For： Automotive Display, Industrial Application,
Touch Panel：Without
Interface Type： Parallel RGB (1 ch， 8-bit)
Environment： Operating Temperature: -30 ~ 80 °C-
