AUO A070VTN06.3 LCD

Specification

Model P/N:A070VTN06.3
Brand:AUO
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 134PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:60/60/40/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×85.92(H) mm
Bezel Opening:157.1(W)×90.92(H) mm
Outline Dim:164.9(H)×100(V) ×6(D) mm
Treatment:-
Luminance:670 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 53% NTSC
Light Source:WLED [3S3P] , 10K hours , W/O Driver
Weight:150g (Typ.)
Designed For:Automotive Display
Frame Rate:60Hz
Touch Panel:Without
Interface Type:Parallel RGB (1 ch, 8-bit) , 50 pins FPC
Power Supply:3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
