A070VTN06.0 AUO LCD panel replacement for Automotive Display

{{ product.price_format }}
{{ product.origin_price_format }}
Stock:
SKU:{{ product.sku }}
Model: {{ product.model }}
weight: {{ product.weight }} Kilogram

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

{{ value.name }}

Condition:

Quantity:





Manufacturer:AUO
Model Name:A070VTN06.0
Screen Size:7.0 inch
Screen Type:LCM,a-Si TFT-LCD
Pixel Number:800(RGB)×480 (WVGA)
Arrangement:RGB Vertical Stripe
Active Area(mm):154.08 × 85.92 (H×V)
Outline(mm): 164.9 × 100× 6 (H×V×D)
Bezel Area(mm):157.1 × 90.92 (H×V)
Treatment:-
Luminance:400 cd/m2 (Typ.)
Contrast Ratio:500 : 1 (Typ.) (TM)
Viewing Angle:60/60/40/60 (Typ.)(CR≥10)
Response:25 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Color Depth:16.7M
Backlight:3S9PWLED, 10K hours, No Driver
Mass: TBD
Used for: Automotive Display,
Refresh Rate:60Hz
Touchscreen:Without
Signal Type: Parallel RGB (1 ch, 8-bit), FPC , 50 pins
Voltage Supply:3.3/10.4/16.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL)
Max. Ratings:: Storage Temp.: -30 ~ 85 °COperating Temp.: -30 ~ 85 °C
