A070STN01.1 AUO LCD panel replacement

Brand：AUO
Model：A070STN01.1
Diagonal Size：7.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1024(RGB)×600[WSVGA]
Configuration：RGB Vertical Stripe
Active Area：153.6(H)×90(V) mm
Outline Dim.：165.75(H)×105.39(V)×3.1(D) mm
Bezel Area：156.8(H)×93.2(V) mm
Treatment：Glare (Haze 0%), Hard coating
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：800:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：3/6 (Typ.)(Tr/Td)
Viewing Angle：80/80/70/80 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K/16.2M 50%(CIE1931)
Light Source：WLED[3S7P], 20K hours, W/O Driver
Weight： 90.0g
Designed For： MP4 PMP, MID UMPC, Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 40 pinsLVDS (1 ch, 6/8-bit), FPC
Power Supply：3.3/11.0/18.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
