AUO A070PAN01.0 CELL LCD

Specification

Model P/N:A070PAN01.0 CELL
Brand:AUO
Diagonal Size:7.0"
Resolution:900(RGB)×1440, WXGA+ 242PPI
Brightness:0 cd/m²
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:94.23(W)×150.77(H) mm
Bezel Opening:-
Response Time:18/12 (Typ.)(Tr/Td)
Outline Size:102.65(W)×161(H) ×0.76(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:16.7M 50% NTSC
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:Without
Panel Weight:29.0g
Application:Pad & Tablet
Signal Interface:MIPI (4 data lanes) , 40 pins Connector
Input Voltage:3.3V (Typ.)
Driver IC:COGBuilt-in 3 source + 2 gate chips
Glass Depth:0.25+0.25 mm
Transmissivity:4.0% (Typ.)(with Polarizer)
