A061FW01 V0 AUO LCD panel replacement for Automotive Display

Panel Brand：AUO
Panel Model：A061FW01 V0
Panel Size：6.1 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：480(RGB)×234
Pixel Format：RGB Vertical Stripe
Display Area：136.08(W)×71.955(H) mm
Bezel Opening：138.2(W)×74.0(H) mm
Outline Size：149(W)×82.9(H) mm
Surface：Antiglare (Haze 25%)
Brightness：450 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：65/65/45/65 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：15/20 (Typ.)(Tr/Td)
Display Colors：Full color 50%(CIE1931)
Lamp Type：6S3PWLED, 10K hours, Without Driver
Frequency：-
Touch Screen：Without
Panel Weight： 113±11g
Application： Automotive Display,
Signal Interface： TFT Specific Analog RGB, 30 pins, FPC
Input Voltage：3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
