A056DN01 AUO LCD panel replacement for Touchscreen

Manufacturer：AU Optronics
Model Name：A056DN011 Compatible
Screen Size：5.6 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：320(RGB)×234
Arrangement：RGB Vertical Stripe
Active Area(mm)：113.28 × 84.708 (H×V)
Outline(mm)： 126.5 × 100 (H×V×D)
Bezel Area(mm)：116.08 × 87.51 (H×V)
Treatment：-
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：150 : 1 (Typ.) (TM)
Viewing Angle：45/45/10/30 (Min.)(CR≥10)
Response：15/20 (Typ.)(Tr/Td) ms
Good View at：6 o’clock
Work Mode：TN, Normally White, Transmissive
Color Depth：
Backlight：1 pcsCCFL, 15K hours, No Driver
Mass： 145±10g
Used for： Video Door Phone, Digital Photo Frame, Portable DVD Player,
Refresh Rate：-
Touchscreen：Without
Signal Type： TFT Specific Analog RGB, FPC , 26 pins
Voltage Supply：5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL)
Max. Ratings： Storage Temp.: -25 ~ 80 °COperating Temp.: 0 ~ 60 °C
