A050FW03 V0 AUO LCD panel replacement

Manufacturer：AUO
Model Name：A050FW03 V0
Screen Size：5.0 inch
Screen Type：LCM，a-Si TFT-LCD
Pixel Number：480(RGB)×272 (WQVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：110.88 × 62.832 (H×V)
Outline(mm)： 120.7 × 75.8× 4.45 (H×V×D)
Bezel Area(mm)：114.7 × 66.03 (H×V)
Treatment：Antiglare， Hard coating (3H)
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle：70/70/40/60 (Typ.)(CR≥10)
Response：7/23 (Typ.)(Tr/Td) ms
Good View at：6 o'clock
Work Mode：TN， Normally White， Transmissive
Color Depth：16.7M
Backlight：6S2PWLED， 10K hours， No Driver
Mass： 75.0g (Typ.)
Used for： Portable Navigation, Pocket TV, MP4 PMP,
Refresh Rate：60Hz
Touchscreen：Embeded (4-wire Resistive)
Signal Type： Parallel RGB (1 ch， 8-bit) + SPI， FPC ， 67 pins
Voltage Supply：3.3V (Typ.)(VDD)
Max. Ratings：： Storage Temp.: -30 ~ 80 °COperating Temp.: -20 ~ 70 °C
