AUO A050FW03 V404 LCD

Specification

Model P/N:A050FW03 V404
Brand:AUO
Diagonal Size:5.0"
Resolution:480(RGB)×272, WQVGA 109PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/40/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:110.88(W)×62.832(H) mm
Bezel Opening:114.7(W)×66.03(H) mm
Outline Dim:120.7(H)×75.8(V) ×4.45(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:400 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:7/23 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 50% NTSC
Light Source:WLED [6S2P] , 10K hours , W/O Driver
Weight:75.0g
Designed For:Portable Navigation ，MP3 PMP
Frame Rate:60Hz
Touch Panel:4-wire Resistive Touch
Interface Type:Parallel RGB (1 ch, 8-bit) , 50 pins FPC
Power Supply:3.3V (Typ.)
