A050FW02 V5 AUO LCD panel replacement

Manufacturer：AUO
Model Name：A050FW02 V5
Screen Size：5.0 inch
Screen Type：LCM，a-Si TFT-LCD
Pixel Number：480(RGB)×272 (WQVGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：110.88 × 62.832 (H×V)
Outline(mm)： 120.7 × 75.8× 4.45 (H×V×D)
Bezel Area(mm)：114.7 × 66.03 (H×V)
Treatment：Antiglare， Hard coating (3H)
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle：70/70/40/60 (Typ.)(CR≥10)
Response：7/23 (Typ.)(Tr/Td) ms
Good View at：6 o'clock
Work Mode：TN， Normally White， Transmissive
Color Depth：262K 54%(CIE1931)
Backlight：7S2PWLED， 10K hours， No Driver
Mass： 80.0g
Used for： Portable Navigation, Pocket TV, MP4 PMP,
Refresh Rate：-
Touchscreen：Embeded (4-wire Resistive)
Signal Type： Parallel RGB (1 ch， 6-bit) + SPI， FPC ， 67 pins
Voltage Supply：3.3V (Typ.)(AVDD);1.7/ (Min.)(DVDD)
Max. Ratings：： Storage Temp.: -30 ~ 80 °COperating Temp.: -30 ~ 70 °C
