A050FTT04.0 AUO LCD panel replacement

Panel Brand：AUO
Panel Model：A050FTT04.0
Panel Size：5.0 inch
Panel Type：a-Si TFT-LCD， LCM
Resolution：480(RGB)×272 ， WQVGA
Pixel Format：RGB Vertical Stripe
Display Area：110.88(W)×62.832(H) mm
Bezel Opening：-
Outline Size：120.73(W)×75.83(H)×4.47(D) mm
Surface：Hard coating (3H)
Brightness：400 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：70/70/40/60 (Typ.)(CR≥10)
Display Mode：TN， Normally White， Transmissive
Best View on：6 o'clock
Response Time：7/23 (Typ.)(Tr/Td)
Display Colors：262K 50%(CIE1931)
Lamp Type：6S1PWLED， 10K hours， Without Driver
Frequency：-
Touch Screen：Embeded (4-wire Resistive)
Panel Weight： 75g
Application： Portable Navigation, Pocket TV, MP4 PMP,
Signal Interface： Parallel RGB (1 ch， 6-bit) + SPI， 67 pins， FPC
Input Voltage：3.3/3.3V (Typ.)(VDD/VDDIO)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
