A043FW02 V8 AUO LCD panel replacement

Brand：AUO
Diagonal Size：4.3 inch
Pixel Format：480(RGB)×272[WQVGA]
Active Area：95.04(H)×53.856(V) mm
Bezel Area：-
Luminance：400 cd/m2 (Typ.)
View Direction：6 o’clock
Viewing Angle：70/70/50/60 (Typ.)(CR≥10)
Support Color：16.7M
Weight：56.8g(Typ.)
Frame Rate： 60Hz
Model：A043FW02 V8
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 105.5(H)×67.2(V)mm
Treatment：Antiglare (Haze 8%), Hard coating (3H)
Contrast Ratio： 300:1 (Typ.) (TM)
Response Time：15/20 (Typ.)(Tr/Td)
Operating Mode： TN, Normally White, Transmissive
Light Source： WLED [10S1P] , 10K hours , W/O Driver
Designed For： Portable Navigation, Pocket TV,
Touch Panel：Embeded (4-wire Resistive)
Interface Type： 40 pinsParallel RGB (1 ch, 8-bit), FPC
Power Supply： 3.3/3.3V (Typ.)(VDD/VDDIO)
Environment： Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C
