A035QN01 V4 AUO LCD panel replacement

Panel Brand：AUO
Panel Model：A035QN01 V4
Panel Size：3.5 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：320(RGB)×240 , QVGA
Pixel Format：RGB Vertical Stripe
Display Area：70.08(W)×52.56(H) mm
Bezel Opening：73.05(W)×55.6(H) mm
Outline Size：76.9(W)×63.9(H)×4.43(D) mm
Surface：Hard coating (3H)
Brightness：350 cd/m2 (Typ.)
Contrast Ratio：350:1 (Typ.) (TM)
Viewing Angle：60/60/50/55 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Display Colors：16.7M 60%(CIE1931)
Lamp Type：6S1PWLED, 10K hours, Without Driver
Frequency：60Hz
Touch Screen：Embeded (4-wire Resistive)
Panel Weight： 42.9g
Application： Digital Still Camera, Digital Video Camera, Portable Navigation, Pocket TV, VOIP Phone,
Signal Interface： Parallel RGB (1 ch, 8-bit) + SPI, 54 pins, FPC
Input Voltage：3.3/5.0/16/-10V (Typ.)(VDD/AVDD/VGH/VGL)
Environment：Operating Temp.: 0 ~ 60 °C ;Storage Temp.: -10 ~ 70 °C
