A030VVN01.0 AUO LCD panel replacement

Panel Brand：AUO
Panel Model：A030VVN01.0
Panel Size：3.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：640(RGB)×480 , VGA
Pixel Format：RGB Vertical Stripe
Display Area：60(W)×45(H) mm
Bezel Opening：62.4(W)×47.4(H) mm
Outline Size：71.4(W)×51(H)×2.4(D) mm
Surface：Reflection 1.45% (Max.)
Brightness：480 cd/m2 (Typ.)
Contrast Ratio：1000:1 (Typ.) (TM)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：15/30 (Typ.)(Tr/Td)
Display Colors：16.7M 50%(CIE1931)
Lamp Type：6S1PWLED, Without Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： 20.0g
Application： Digital Still Camera, Digital Video Camera,
Signal Interface： Parallel RGB (1 ch, 8-bit) + SPI, 45 pins, FPC
Input Voltage：3.3/3.3/3.3V (Typ.)(VCI/VDD/VDDIO)
Environment：Operating Temp.: -10 ~ 60 °C ;Storage Temp.: -30 ~ 70 °C
