AUO A030JN01 V0 LCD

Specification

Model P/N:A030JN01 V0
Brand:AUO
Diagonal Size:3.0"
Resolution:960×480 195PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:60/60/50/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Delta
Active Area:60(W)×45(H) mm
Bezel Opening:62.0(W)×47.4(H) mm
Outline Dim:70.2(H)×51.4(V) ×2.4(D) mm
Treatment:Hard coating
Luminance:400 cd/m² (Typ.)
View Direction:-
Response Time:10/25 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M
Light Source:WLED [4S1P] , W/O Driver
Weight:TBD
Designed For:Digital Still Camera ，Digital Video Camera
Frame Rate:60Hz
Touch Panel:Without
Interface Type:YUV (16-bit) , 51 pins FPC
Power Supply:3.3/3.3V (Typ.)(VDD/VDDIO)
