AUO A027DTN01.A LCD

Specification

Model P/N:A027DTN01.A
Brand:AUO
Diagonal Size:2.7"
Resolution:320(RGB)×240, QVGA 150PPI
Brightness:400 cd/m² (Typ.)
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:60/60/50/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Delta
Active Area:54(W)×40.5(H) mm
Bezel Opening:56.4(W)×42.9(H) mm
Response Time:10/25 (Typ.)(Tr/Td)
Outline Size:63.5(W)×46.6(H) ×2.4(D) mm
Surface:Hard coating
Best View on:-
Display Colors:16.7M 50% NTSC
Lamp Type:2S1P WLED , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:13.7g
Application:Digital Still Camera ，Digital Video Camera
Signal Interface:Serial RGB (8-bit) + SPI, CCIR601/656 , 41 pins FPC
Input Voltage:1.8/3.3V (Typ.)(VDDIO/VDD)
