A025DN01 V3 AUO LCD panel replacement for Touchscreen

Manufacturer：AUO
Model Name：A025DN01 V3
Screen Size：2.5 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：320(RGB)×240 (QVGA)
Arrangement：RGB Delta
Active Area(mm)：49.92 × 37.44 (H×V)
Outline(mm)： 59.63 × 43.7 (H×V×D)
Bezel Area(mm)：52.52 × 40.04 (H×V)
Treatment：Hard coating
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：300 : 1 (Typ.) (TM)
Viewing Angle：70/70/70/70 (Typ.)(CR≥10)
Response：15/20 (Typ.)(Tr/Td) ms
Good View at：-
Work Mode：TN, Normally White, Transmissive
Color Depth：16.7M
Backlight：3S1PWLED
Mass： 14.5g
Used for： Digital Still Camera, Digital Video Camera,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： Serial RGB (8-bit) + SPI, CCIR601/656, FPC , 40 pins
Voltage Supply：3.3/15/-10V (VDD/VGH/VGL)
Max. Ratings： Storage Temp.: -25 ~ 80 °COperating Temp.: -10 ~ 60 °C
