A025DL02 V5 AUO LCD panel replacement

Manufacturer：AUO
Screen Size： 2.5 inch
Pixel Number： 320(RGB)×240(QVGA)
Active Area(mm)：50.4 × 37.8 (H×V)
Bezel Area(mm)：52.6 × 40.0 (H×V)
Luminance：400 (Typ.)(cd/m2)
Viewing Angle：55/55/45/70 (Typ.)(CR≥10)
Good View at：6 o’clock
Color Depth：16.7M
Mass： 17.0g
Refresh Rate：-
Model Name：A025DL02 V5
Screen Type：LCM ,LTPS TFT-LCD
Arrangement：RGB Delta
Outline(mm)： 60.73 × 45.07(H×V×D)
Treatment：Hard coating (3H)
Contrast Ratio： 300 : 1 (Min.) (TM)
Work Mode： TN, Normally White, Transmissive
Response：15/20 (Typ.)(Tr/Td) ms
Backlight：3S1P WLED
Used for： Digital Still Camera, Digital Video Camera,
Touchscreen：Without
Signal Type：Serial RGB (8-bit) + SPI, CCIR656, FPC, 39 pins
Voltage Supply： 3.3/3.3 (Typ.)(VDC/VDCI)
Max. Ratings： Storage Temp.: -25 ~ 80 °C Operating Temp.: 0 ~ 60 °C
