A024CN03 V2 AUO LCD panel replacement for Touch Panel

Brand：AUO
Model：A024CN03 V2
Diagonal Size：2.4 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：480×234
Configuration： RGB Delta
Active Area：48(H)×35.685(V) mm
Outline Dim.：54.9(H)×47.45(V) mm
Bezel Area：50.60(H)×38.29(V) mm
Treatment：Hard coating
Luminance：250 cd/m2 (Typ.)
Contrast Ratio： 250:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：20/30 (Typ.)(Tr/Td)
Viewing Angle：45/45/15/35 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：16.7M
Light Source：WLED
Weight： 10.9g (Typ.)
Designed For： Digital Still Camera, Digital Video Camera, Printer,
Frame Rate：-
Touch Panel：Without
Interface Type： 40 pinsSerial RGB (8-bit) + SPI, CCIR656, FPC
Power Supply：3.3/3.3/12.5/-12.5V (Typ.)(VCC/PVDD/VGH/VGL)
Environment： Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -25 ~ 70 °C
