AUO A020CN01 V2 LCD

Specification

Model P/N:A020CN01 V2
Brand:AUO
Diagonal Size:2.0"
Resolution:480×240 147PPI
Contrast Ratio:180 : 1 (Typ.) (TM)
Viewing Angle:40/40/10/30 (Typ.)(CR≥10)
Color Depth:16.7M
Backlight:WLED , 10K hours , No Driver
Signal Type:Serial RGB (8-bit) + SPI , FPC 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Delta
Active Area:39.84(W)×29.88(H) mm
Bezel Opening:42.22(W)×32.48(H) mm
Treatment:Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Response:23/30 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Digital Still Camera
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.0/3.3V (Typ.)(VCC/AVDD)
Max Ratings:Storage Temp.: -55 ~ 125 °C Operating Temp.: -30 ~ 85 °C
Outline (mm):47.54×41.08×2.74 (H×V×D)
