Innolux 85C02007-001 LCD

Specification

Model P/N:85C02007-001
Brand:Innolux
Diagonal Size:2.0"
Resolution:240(RGB)×320, QVGA 201PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:20/50/45/45 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:30.24(W)×40.32(H) mm
Bezel Opening:-
Outline Dim:34.42(H)×48.56(V) ×1.27(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:3 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 50% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.50+0.50 mm
Transmittance:6.36% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest HX8347, ILI9325
