70WVW5A SII LCD panel replacement

Brand：SII
Model：70WVW5A
Diagonal Size：7.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：800(RGB)×480[WVGA]
Configuration：RGB Vertical Stripe
Active Area：152.4(H)×91.44(V) mm
Outline Dim.：165.2(H)×105.9(V)×8.38(D) mm
Bezel Area：155.25(H)×94.3(V) mm
Treatment：Antiglare
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：400:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：5/11 (Typ.)(Tr/Td)
Viewing Angle：70/70/55/65 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K/16.2M 45%(CIE1931)
Light Source：WLED[7S3P], W/O Driver
Weight： 145g (Typ.)
Designed For： Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 6/8-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
