35QVW1H SII LCD panel replacement for Portable Navigation

Panel Brand：SII
Panel Size：3.5 inch
Resolution：320(RGB)×240 , QVGA
Display Area：70.08(W)×52.56(H) mm
Outline Size：76.9(W)×63.9(H)×3.4(D) mm
Brightness：450 cd/m2 (Typ.)
Viewing Angle：70/70/50/65 (Typ.)(CR≥10)
Best View on：6 o’clock
Display Colors：262K60%(CIE1931)
Frequency：-
Weight：26.0g (Typ.)
Panel Model：35QVW1H
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：72.5(W)×54.2(H) mm
Surface：Clear, Hard coating
Contrast Ratio：400:1 (Typ.) (TM)
Display Mode： TN, Normally White, Transmissive
Response Time：15/35 (Typ.)(Tr/Td)
Lamp Type： 6S1P WLED
Touch Screen：Without
Application： Portable Navigation,
Signal Interface： Parallel RGB (1 ch, 8-bit) + SPI, 50 pins , FPC
Environment： Operating Temp.: -20 ~ 60 °C ;Storage Temp.: -30 ~ 70 °C
