P0760WVLC-T CMEL LCD panel replacement for Touch Panel

Brand：CMEL
Model：P0760WVLC-T
Diagonal Size：7.6 inch
Type：AM-OLED, OLED
Pixel Format：800(RGB)×480[WVGA]
Configuration： RGB Vertical Stripe
Active Area：165.6(H)×99.36(V) mm
Outline Dim.：177.3(H)×118.32(V) mm
Bezel Area：169.0(H)×102.8(V) mm
Treatment：Reflection 3.0% (Max.)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio： 30000:1 (Min.) (TM)
View Direction：-
Response Time：0.05/0.05 (Max.)(Tr/Td)
Viewing Angle：85/85/85/85 (Min.)(CR＞10)
Operating Mode：-
Support Color：16.7M 70%(CIE1931)
Light Source：self, 30K hours
Weight： 150g (Typ.)
Designed For： MP4 PMP, MID UMPC, Digital Photo Frame, Portable DVD Player,
Frame Rate：-
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 8-bit) + SPI, Connector
Power Supply：5.0V (Typ.)
Environment： Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -40 ~ 85 °C
