AUO A070FW03 V4 LCD

Specification

Model P/N:A070FW03 V4
Brand:AUO
Diagonal Size:7.0"
Resolution:480(RGB)×234 76PPI
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:65/65/40/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×86.58(H) mm
Bezel Opening:-
Outline Dim:164.9(H)×100(V) ×6(D) mm
Treatment:Antiglare (Haze 25%)
Luminance:400 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:12/18 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:Full color
Light Source:CCFL [1 pcs] , 10K hours , W/O Driver
Weight:155±10g
Designed For:Digital Photo Frame ，Portable DVD Player ，Video Door Phone
Frame Rate:-
Touch Panel:Without
Interface Type:TFT Specific Analog RGB , 26 pins FPC
Power Supply:5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL)
